Automation of OpenStack Backups
The OpenStack Horizon UI allows the manual creation of backups and snapshots from individual instances and volumes, but does not provide automation features for backing up or restoring multiple resources nor it offers options for the scheduling of backups. The OpenStack Command Line Interface (CLI) provides the same capabilities, without any automation features. The scheduling of backups using the OpenStack CLI must be done using cron jobs. Documentation on how to use the OpenStack CLI to create and schedule backups can be found here and to restore backups here. With this script, users can create, schedule or restore multiple backups automatically.
Functionality
This script automates the creation, restoration and scheduling of backups using the OpenStack SDK. This allows users with OpenStack credentials to create backups or snapshots of multiple instances and their attached volumes, scheduling backups for a future time with and without repetition and with and without a retention count. It also allows the restoration of multiple instances or volumes, in-place or to a new instance or volume.
Prerequisites
python>=3.12openstacksdk>=3.0.0PyYAML>=6.0.1schedule>=1.1.0
OR
docker>=29.1.3
Usage
The script can be run either directly using the current python environment, satisfying the prerequisites above, or inside a docker container. In either case, it is necessary to first set up the authentication credentials file and the configuration file. It is highly recommended not to run this script within the VM you wish to back up or restore.
1. Application credentials
To run this script it is necessary to have the required OpenStack application credentials to access the project/domain/cloud specified in the configuration file. You can find information on how to create application credentials and obtain the RC file or clouds.yaml file in here
2. Configuration file
A configuration YAML file that contains the requested information to create, schedule or restore backups is required to run the script. A template YAML file can be found in the templates directory and some examples in the tests directory. The structure of this configuration file is as follows
cloud: <cloud_name>
authentication: <credentials_method>
backup:
- name: <resource_name>
type: <resource_type>
mode: <backup_mode>
- ...
restore:
- name: <resource_name>
type: <resource_type>
mode: <backup_mode>
- ...
where the <cloud_name> corresponds to the name of cloud (domain name) to which the various resources belong. The authentication node indicates the mode in which the credentials will be provided, which should be either openrc if the application credentials have been sourced from an OpenRC file, or clouds.yaml if the application credentials are stored in an eponymous file in the current directory. The optional backup node contains instructions to create and schedule backups, as explained below, and the optional restore node contains instructions to restore backups.
2.1 Creating backups
The instructions to create backups must be provided in the backup node of the configuration file, following the structure
...
backup:
- name: <resource_name>
type: <resource_type>
mode: <backup_mode>
attachments:
- name: <attachment_name>
type: <attachment_type>
mode: <attachment_backup_mode>
- ...
- ...
where <resource_name> is the name of the instance or volume to back up, <resource_type> is either instance or volume and <backup_mode> is either snapshot or backup. Any number of entries, corresponding to the resources to backup, can be provided to the backup node. By default, attachments are not backed up along with the resource (with the exception of root volume of volume-backed instances). In order to back these up, one must provide the attachment field to the resource, as seen above. It is possible to select to backup all attachments of the resource, with attachments: all, or a specific set, by providing a list of the resources to backup. It is recommended to stop instances and detaching volumes before backing them up. This is the default behaviour. The options stop and detach can be supplied to instances and volumes, respectively, to change this default behaviour.
2.2 Scheduling backups
In order to schedule backups, one can add the scheduler field to any resource in the backup node. The scheduler node must containt, at least, the start field, which determines when to run the backup, in the format "yyyy-mm-dd, HH:MM". If repeated backups are desired, the field repeat_every can be either day or week, to repeat the backup daily or weekly. To stop the scheduled backups at some future point in time, the field end contains the date on which the scheduler will stop. Lastly, to only keep some amount of backups at a given time, the field retention_count can be provided. An example scheduled backup of an instance my_instance in my_cloud, to run weekly from the first of April of 2026 for a year, with a maximum of five backups on disk, could be
cloud: my_cloud
backup:
- name: my_instance
type: instance
mode: snapshot
scheduler:
start: "2026-04-01, 00:00",
end: "2027-04-01, 00:00",
repeat_every: week,
retention_count: 5
Note: it is not allowed to set up scheduled backups using this script more than a week apart. If one wishes to set this up, a cron job is recommended.
2.3 Restoring backups
The restore node in the configuration file is used to specify any backups to be restored. The backup and restore nodes are not mutually exclusive, if both are provided all operations will be run. The structure of the restore node is as follows
...
restore:
- name: <resource_name>
type: instance
mode: <backup_mode>
in_place: False
new_name: <new_resource_name>
flavor: <new_flavor>
network: <new_network>
- name: <resource_name>
type: <resource_type>
mode: <backup_mode>
in_place: True
- ...
where, as before, <resource_name> is the name of the instance or volume to restore, <resource_type> is either instance or volume and <backup_mode> is either snapshot or backup. The attachments of resources are not automatically restored, and if required to be restored, they should just be added to the list as another resource to restore in the same way. The field in_place, which defaults to False, can be provided for each resource and determines whether to restore in-place or as a new resource. For non-in-place restorations the field new_name can also be provided to fix the name of the new resource, otherwise a new name will be created for it. The non-in-place restoration of instances requires also the fields flavor and network, and optionally security_groups, as these are required to create a new server.
3. Running the script
As stated above, this script can be run directly within the current python environment or in a docker container. To run it directly using python, one must simply provide a positional argument corresponding to the path to the configuration file.
$ python openstack_backups.py -h
usage: openstack_backups.py [-h] config_file_path
positional arguments:
config_file_path Path to configuration file for the backups
options:
-h, --help show this help message and exit
As an example, to run the test configuration file provided in the tests directory, which schedules daily instance snapshots of a server called TestVM, do
python openstack_backups.py test/test_backup.yaml
4. (Optional) Running the container
Optionally, instead of running the script in a local python environment, it can be run within a docker container. These can be done, after preparing the custom clouds.yaml and configuration file, by following these steps:
4.1 Specify the location of the configuration file
First one must modify the last line of the Dockerfile file to specify the location of the configuration file of choice:
ENTRYPOINT ["pipenv", "run", "python", "openstack_backups.py", "<custom_configuration_yaml_file>"]
4.2. Create the docker image
Then one must create the docker image with
sudo docker build . -t openstack-backups
Note that this step might take some time
4.3 Launch the docker container
Lastly one can launch the docker container with
sudo docker run openstack-backups
Inputs
As described in the usage above, two inputs are required
- Authentication file. Must be called
clouds.yamland present in the directory where the script is run. - Configuration file. YAML file with the instructions to create, schedule or restore backups.
